SITMA 750

Basic information

• Production Year: 2004

More Details

• Automatic Inserting and Polywrapping Line for Printed Materials and Direct Mail
• A high-performance automatic packaging line designed for collating, personalizing, and polywrapping printed materials, magazines, catalogs, direct mail items, and other products.
• The system enables automatic insertion of multiple inserts, application of three-dimensional items, address personalization, labeling, and subsequent packaging in shrink or non-shrink film.
• Main Features
• Automatic feeding of the main product
• Opening of the product under the cover or in the center fold
• Insertion of up to 6 flat (2D) inserts
• Insertion and optional gluing of one three-dimensional (3D) item
• Application of self-adhesive labels
• Printing of two independent addresses on the finished package
• Film wrapping with side-seal or top-seal configuration
• Capability to use pre-printed film with precise registration and cutting
• Film shrinking in a heat tunnel
• Cross-stacking of finished mail pieces
• Packaging Parameters
• Without 3D item
• Minimum size: 130 × 150 mm
• Product thickness: 2–30 mm
• With 3D item
• Minimum size: 175 × 250 mm
• Total package thickness: up to 30 mm
• Maximum 3D item height: 25 mm
• Film Specifications
• Film width: 250–700 mm, depending on sealing configuration
• Film thickness: 13–50 μm (recommended: 22–35 μm)
• Maximum film roll diameter: 600 mm
• Advantages
• Modular design
• High format flexibility
• Integrated personalization, addressing, and packaging
• Capability to insert both 2D and 3D inserts
• Processing of pre-printed films with precise registration and trimming
• SITMA 750 Polywrapping Line
• The SITMA 750 packaging line is designed for automatic insertion of supplements, personalization, application of three-dimensional items, film wrapping, and address printing.
• Main Technical Specifications
• Main Product Format
• Minimum: 100 × 150 mm
• Maximum: 300 × 420 mm
• Main Product Thickness
• 2–30 mm
• Maximum stack height in feeder: 60 mm
• Insert Capacity
• Up to 6 flat (2D) inserts
• 1 three-dimensional (3D) item
• 1 self-adhesive label
• Addressing
• Printing of two addresses on the finished package
• Package Sealing
• Side-seal or top-seal configuration
• Compatible with pre-printed film and precise registration cutting
• Package Thickness
• 2–30 mm without 3D item
• Up to 30 mm including 3D item
• Film Specifications
• Top seal
• Film width: 299–700 mm
• Side seal
• Film width: 344–600 mm
• Recommended film thickness
• 22–35 μm

Condition of the Machine

• Functional, condition and wear and tear according to its age, well maintained.
• Not in production but still plugged in.

• Availability: immediately
• Sale Reason: production reduction
• Disclaimer: The Condition of the Machine assessment presented in this CV was either obtained from the last machine operator or is based on an inspection performed by our employee, just to provide you with as much information as possible.
  For more certainty we recommend your own check or an assessment of an independent mechanic. We cannot provide you with any machine guarantee.
