MAN LITHOMAN 72
Heat-set Web Offset Printing Machine
#24015
Machine CV Download the offer as PDF
In some way, the machines in our offer are like human job applicants. Some machines are almost new, like a freshly graduated person, while others already have many years of work experience behind themselves. Some machines are more suitable for one kind of activity, whereas others are more suitable for another kind of activity. But, what all the machines have in common is that, from various reasons, all of them are at the moment freed from their last services and are searching for the possibility of a new employment. So, through the CV of every particular machine, meet all the information we were able to get on them.
Basic information
- Manufacturer: MAN Roland websystem GmbH, Ausburg, Germany
- Production Year: 2010
- Number of Colours: 4
- Cut-off: 620 mm
- Max. Speed: 45000 imp./hour
More Details
- paper grammage 40–100 g/m2
- print direction left to right
- circumference:1240 mm 2.060 mm
- 1 automatic reel feeding system MAN Roland AUROload 2.1
- 1 MEG splicer MEGTEC – D.L.C. 5000 incl. Infeed unit
- 1 Web Monitoring system Procemex, type Procemex -7x
- 1 Webbing up system MAN Roland make, from splicer up to the former
- 4 MAN Roland Lithoman Printing units with PPL and automatic plate change APL 1 Blanket washing system Oxy Dry
- 1 automatic ink roller washing sytem Baldwin, type APW
- 1 dampening solution unit Technotrans, type delta.d 400 W
- 1 Ink supply system for 4 printing units, manroland/technotrans make
- 1 Web catching device Baldwin, type webchatcher s18i
- 1 MEGTEC dryer, type Dual Dry RTO 157, incl. TNV, 15,7 m drying length
- 1 MAN Roland chilling unit with 6 chill rollers and 3 Cooling circuits (1+2+3 Rollers) 1 Washing unit for first and second chilling roller, manroland/Baldwin make
- 1 Remoistener unit Eltex, type Webmoister 3000
- 1 Color density control system QuadTech, type CCS-IF-WR with central reporting 1 Folder superstructure incl.
- silicon unit, manroland-Weko, type WFG 1.4
- web edge aligner Erhardt & Leimer
- color register control Quad Tech, type Register Guidance
- fotoelectric cutting register control Quad Tech, type Ribbon Control System
- longitudinal gluing and folding aid Robatech, system Webtack A
- longitudinally movable former
- 1 additional Folding Group, (Piggyback Folder) on top of the main folder
- for production of 8 X 8 pages A4, 8 x 10 pages A4, 8 x 12 pages A4 1 MAN Folder PFI/3-2, system 2:3:3:3
- 1 cylinder sticher for A3
- 1 drive equipment, single motor drive for, printing units, chiller unit, draw rollers
- former roller, folder
- 2. 2 Press Console
- 1 Press control system with
- PECOM press Basic
- PECOM Extended
- PECOM printnet pressport
- 1 fully automatic plate punch
- 1 Refrigeration Center Cofely with cooling tower
- drawings, tools and manuals as available at the present place of installation.
Condition of the Machine
- Very good condition, well maintained, worn out according to its age.
- Not in production but still plugged in.
- Availability: immediately
- Sale Reason: closing company
-
Disclaimer:
The Condition of the Machine assessment presented in this CV was either obtained from the last machine operator or is based on an inspection performed by our employee, just to provide you with as much information as possible.
For more certainty we recommend your own check or an assessment of an independent mechanic. We cannot provide you with any machine guarantee.
