NILPETER FA 3300
Flexographic Printing Machine
#24030
Machine CV Download the offer as PDF
In some way, the machines in our offer are like human job applicants. Some machines are almost new, like a freshly graduated person, while others already have many years of work experience behind themselves. Some machines are more suitable for one kind of activity, whereas others are more suitable for another kind of activity. But, what all the machines have in common is that, from various reasons, all of them are at the moment freed from their last services and are searching for the possibility of a new employment. So, through the CV of every particular machine, meet all the information we were able to get on them.
Basic information
- Manufacturer: NILPETER A/S., Slagelse, Denmark
- Production Year: 2004
- Number of Colours: 5
- Web-width: 333 mm
More Details
- max. mechanical speed 175 m/min
- number of printing units: 5 (all UV and hot air drying)
- min. material width: 150 mm
- max. material width: 333 mm
- printing cylinders: 5 x 85, 96 and 114 teeth
- magnetic cylinder: 85, 96 and 114 teeth
- anilox cylinder: 10 pcs
- UV lamps
- max. diameter of unwind roll: 750 mm
- max. diameter of winding roll: 700 mm
- printed 41 500 hours
- 5 x ink system
- 1x varnish blade
- 3 x back pressure cylinder
- 2 x varnish cylinder
- 50 x doctor blade planchette
- anilox cylinder
- 1 x 440/3,35
- 1 x 120/9,4
- 1 x 440/3,35
- 1 x 480/2,4
- 1 x 220/5
- magnetic cylinder: 80, 85, 96, 114 teeth
- printing cylinder:
- 5 x 80 teeth
- 5 x 85 teeth
- 5 x 96 teeth
- 5 x 114 teeth
- gear wheel: 5 x (80, 85, 96, 114 teeth)
- 14 x UV lamp
- 14 x source
- 20 x flap for UV lamp
- 3 x bottom cassette
- 1 x top cassette
Condition of the Machine
- Functional, condition and wear and tear according to its age, well maintained.
- Can be seen running.
- Availability: immediately
- Sale Reason: production reduction
-
Disclaimer:
The Condition of the Machine assessment presented in this CV was either obtained from the last machine operator or is based on an inspection performed by our employee, just to provide you with as much information as possible.
For more certainty we recommend your own check or an assessment of an independent mechanic. We cannot provide you with any machine guarantee.
