Inserting Machine


Special Offer
A Curriculum Vitae (CV), (also spelled curriculum vitæ), provides an overview of a person's experience and other qualifications. In some countries, a CV is typically the first item that a potential employer encounters regarding a job seeker and is typically used to screen applicants, when seeking employment. Curriculum Vitae is a Latin expression which can be loosely translated as [the] course of [my] life.

In some way, the machines in our offer are like human job applicants. Some machines are almost new, like a freshly graduated person, while others already have many years of work experience behind themselves. Some machines are more suitable for one kind of activity, whereas others are more suitable for another kind of activity. But, what all the machines have in common is that, from various reasons, all of them are at the moment freed from their last services and are searching for the possibility of a new employment. So, through the CV of every particular machine, meet all the information we were able to get on them.

Basic information

  • Manufacturer: Müller Martini AG, Zofingen, Switzerland
  • Production Year: 2006
  • Counter: 18768 hours

More Details

  • double gripper feeder
  • 2 vibrating table for the preparation of inserts
  • 2 streamfeeders AF 300
  • 2 machine modules for the feeder
  • 2 machine modules with double gripper feeder
  • 50 meter SG 3000 display chain with brackets
  • 25 meter track profile for News-Grip-A including delivery station
  • 137 pocket inserts
  • 1 stacker feed
  • 1 VTLF 250 SK Becker compressor
  • 1 stacker type FORTE
  • feed speed max. 1.2 m/s
  • format: max. length 500 mm
  • min. length 148 mm
  • max. width 340 mm
  • min. width 105 mm
  • 1 PTP online system
  • 1 PTH online system
  • feeding from FlexiRoll
  • feeder manually or with a flow feeder
  • stack height max. 350 mm
  • mechanical output: 100,000 samples per hour
  • double sheet control
  • WinLink control (Windows NT platform)
  • management and monitoring of the entire system
  • optional function modules for creating packets
  • addressing
  • fully automatic zone control for a targeted supply of accessories
  • servo drive technology
  • production statistics
  • built-in remote maintenance function (modem/LAN)
  • MIRS (Missing Inserts Repair System)
  • system of filling in wrong ones deductions
  • increasing the quality of the final product
  • elimination of manual work and waste

Condition of the Machine

  • Functional, condition and wear and tear according to its age, well maintained.
  • Not in production but still plugged in.
  • Availability: immediately
  • Sale Reason: production reduction
  • Disclaimer: The Condition of the Machine assessment presented in this CV was either obtained from the last machine operator or is based on an inspection performed by our employee, just to provide you with as much information as possible.
    For more certainty we recommend your own check or an assessment of an independent mechanic. We cannot provide you with any machine guarantee.


If you would like us to arrange Turnkey Dismantling, Loading, Transport or Installation for you – See Services
