KOLBUS SIGLOCH - KOLBUS BF 511 Compact Casing-in-line HB 530 with Sigloch hard cover book production
Hardcover Binding Line
#R 23557
Machine CV Download the offer as PDF
A Curriculum Vitae (CV), (also spelled curriculum vitæ), provides an overview of a person's experience and other qualifications. In some countries, a CV is typically the first item that a potential employer encounters regarding a job seeker and is typically used to screen applicants, when seeking employment. Curriculum Vitae is a Latin expression which can be loosely translated as [the] course of [my] life.
In some way, the machines in our offer are like human job applicants. Some machines are almost new, like a freshly graduated person, while others already have many years of work experience behind themselves. Some machines are more suitable for one kind of activity, whereas others are more suitable for another kind of activity. But, what all the machines have in common is that, from various reasons, all of them are at the moment freed from their last services and are searching for the possibility of a new employment. So, through the CV of every particular machine, meet all the information we were able to get on them.
In some way, the machines in our offer are like human job applicants. Some machines are almost new, like a freshly graduated person, while others already have many years of work experience behind themselves. Some machines are more suitable for one kind of activity, whereas others are more suitable for another kind of activity. But, what all the machines have in common is that, from various reasons, all of them are at the moment freed from their last services and are searching for the possibility of a new employment. So, through the CV of every particular machine, meet all the information we were able to get on them.
Basic information
- Manufacturer: Kolbus GmbH & Co KG, Rahden, Germany
- Production Year: 2005
- Max. Size/Width: 310x420 mm (12.2"x16.5")
- Counter: 23 mil. revs.
More Details
- complete book casing in line including Sigloch Book Block Production Line - consisting of: Kolbus BF 511 Compact Casing-in-Line
- Co-Pilot with touch screen
- Book Block Feeding Conveyor AB
- Nipping Press NH-4
- Book Back Gluing and Backlining Machine Sigloch BBL 30/2 with end sheet feeding station VAS
- disperse pre-gluing
- hotmelt gluing
- Cycle-Dividing Switch TW
- Drying System TFD
- pre-heating box for hotmelt gluing Sigloch LH 370
- Nipping Press Sigloch NH-1
- speed: 40 tacts/minute
- Kolbus LEH 3 in line ribbon inserter
- KJolbus TS.L conveyors
- Kolbus HD 130 three knife trimmer
- 2700 cuts/hour speed
- Kolbus TS.L conveyor
- Kolbus HB 530 preheat channel
- Side IR heating, speed up conveyor
- IR heating 9 kW with regulation
- Kolbus TS.L conveyor
- Kolbus BF 511 casing-in-line
- rounder and backer
- head and tail banding
- casing in forming and pressing
- SPS drive
- COPILOT system with touch screen
- Sigloch LEH-3
- MF-ASM320 automatic stacker taking books from a sewer
- material cardboard max 3 mm, min 1.25 mm
- inner sheets max 250 g/m2, min 60 g/m2
- List of moduls:
- Kolbus BF 511
- HB 530
- TS.L
- LEH 3
- FD 370 K
- HD 130 three knife trimmer
Condition of the Machine
- Functional, condition and wear and tear according to its age, well maintained.
- Can be seen running.
- Availability: immediately
- Sale Reason: production reduction
-
Disclaimer:
The Condition of the Machine assessment presented in this CV was either obtained from the last machine operator or is based on an inspection performed by our employee, just to provide you with as much information as possible.
For more certainty we recommend your own check or an assessment of an independent mechanic. We cannot provide you with any machine guarantee.
