Gathering and Perfect Binding Line


Special Offer Video
A Curriculum Vitae (CV), (also spelled curriculum vitæ), provides an overview of a person's experience and other qualifications. In some countries, a CV is typically the first item that a potential employer encounters regarding a job seeker and is typically used to screen applicants, when seeking employment. Curriculum Vitae is a Latin expression which can be loosely translated as [the] course of [my] life.

In some way, the machines in our offer are like human job applicants. Some machines are almost new, like a freshly graduated person, while others already have many years of work experience behind themselves. Some machines are more suitable for one kind of activity, whereas others are more suitable for another kind of activity. But, what all the machines have in common is that, from various reasons, all of them are at the moment freed from their last services and are searching for the possibility of a new employment. So, through the CV of every particular machine, meet all the information we were able to get on them.

Basic information

  • Manufacturer: Heidelberg Druckmaschinen A.G., Germany
  • Production Year: 2010

More Details

  • collating station EG 4000
  • stream feeder
  • collation of signatures and individual sheets
  • 4 feeding modules in total 16 feeders
  • automatic format setting
  • one manual feeding station
  • perfect binder Eurobinding 4000
  • automatic adjustment
  • Hotmelt and PUR gluing
  • 2 rollers with squeegees
  • heated glue application roller
  • automatic preheating
  • 18 clamps
  • max. speed 4000 cycles / hour
  • block height 140 - 450 mm
  • block width 100 - 320 mm
  • block thickness 2 - 60 mm
  • cover stream feeder
  • automatic format setting
  • automatic creasing settings
  • cover width 202 - 710 mm
  • cover height 140 - 450 mm
  • cover material 80 - 350 g / m2
  • cooling tower Eurocool 4000
  • speed synchronization with gluing speed
  • three knife trimmer ET C 4000
  • max. 3900 cycles / hour
  • block height trimmed 100 - 420 mm
  • block width trimmed 100 - 305 mm
  • block thickness trimmed 2 - 80 mm

Condition of the Machine

  • Very good condition, well-maintained.
  • Not in daily production but can be seen running at your request.
  • Availability: immediately
  • Sale Reason: closing company
  • Disclaimer: The Condition of the Machine assessment presented in this CV was either obtained from the last machine operator or is based on an inspection performed by our employee, just to provide you with as much information as possible.
    For more certainty we recommend your own check or an assessment of an independent mechanic. We cannot provide you with any machine guarantee.
